Polymer insulator/DMD paper composite
Polymer insulator/DMD paper composite

Polymer insulator/DMD paper composite

Product Details:
Place of Origin: china
Brand Name: HAOXIANG
Model Number: 6641
Payment & Shipping Terms:
Minimum Order Quantity: 100 Kilogram/Kilograms DMD paper composite is 3-layer
Packaging Details: cartons rolls pallets
Delivery Time: within 10 days after receipt of advance payment
Payment Terms: L/C,T/T
Supply Ability: 100 Ton/Tons per Week polymer insulator
Contact Now

Product Description


DMD motor insulation paper
Polyester film/Polyester fiber non-woven fabric
F class(155)
Polymer insulator
1000mm wide

POLYMER INSULATOR DMD/DMD PAPER COMPOSITE/ INSULALTION PAPER OIL IMMERSE

-

-

1.-Composition:

Total-three-Layers:-Dacron+Mylar+Dacron(-Two-layer-polyester-non-woven-fiber-fabric-

adhered-to-either-side-of-one-layer-Polyester-film-in-the-center).

-

2.-Features:

Super-dielectric-property.

Reliable-heat-resistance.

High-mechanical-strength.

Good-impregnating-performance.

-

3.Applications:

It-is-suitable-for-F-class-motors,-generators,-transformers-and-other-electric-appliances-

or-equipment,-insulation

based-on-slot,-liners-and-interturn.

Technical-Specification

Unite

Values

Thickness

mm

0.15

0.18

0.20-

0.23

0.25

0.30-

0.35

0.40-

0.45

Thickness-Tolerance

mm

±0.02

±0.025

±0.03

±0.03

±0.03

±0.03

±0.035

±0.040

±0.045

Nominal-Grammage-and-tolerance-

g/

140±20

190±28

220±33

260±39

300±45

350±52

425±63

500±75

560±84

Thickness-of-polyester-film

mm

0.05

0.075

0.10-

0.125

0.15

0.19

0.25

0.3

0.35

Tensile-Strength

MD

No-Bending

N/10

mm-Width

≥80

≥120

≥140

≥180

≥190

≥270

≥320

≥340

≥370

After-Bending

≥80

≥105

≥120

≥150

≥170

≥200

≥300

≥320

≥350

TD

No-Bending

≥80

≥105

≥120

≥150

≥170

≥200

≥300

≥320

≥350

After-Bending

≥70

≥90

≥100

≥120

≥130

≥150

≥200

≥220

≥250

Elongation

MD

No-Bending

-

≥15

-

-

-

After-Bending

≥10

≥5

≥3

-

TD

No-Bending

≥20

-

-

-

After-Bending

≥10

≥5

≥2

-

Breakdown-Voltage

KV

≥6

≥7

≥9

≥10

≥12

≥15

≥18

≥20

≥22

Bond-strength-at-25-degree-C

-

No-delamination

Bond-strength-at-180-degree-C

-

No-delamination,no-blister,no-adhesive-flow

Temperature

-

155

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-
